Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: GDPY
  • Model Number: PY5W4-Y-T
  • Type: LED
  • Package Type: Surface Mount
  • Max. Forward Voltage: 1.7-3.6V
  • Max. Reverse Voltage: 5V
  • Max. Forward Current: 350-750mA
  • Max. Reverse Current: 10uA
  • Product name: red green yellow white 1w 3w led high power diodes
  • Led Chip brand: Epileds/Epistar
  • Emitting color: Red,Green,Blue,Yellow,Orange(Amber),Purple,White,Multicolor,Flashing
  • Wavelength: 360-630NM
  • Life: up 50000Hours
  • Available power: 1w to 500w
  • Feature: High efficiency&Energy saving
  • work temperature: -20℃to+85℃
  • warranty: 3 years
  • Viewing angle: 140 degree(other angle is available)

Packaging & Delivery

Packaging Details 1000pcs high power led diodes with a sealed Anti-Static bag, several bags with a carton
Delivery Time 3-10 days after payment

                            red green yellow white 1w 3w led high power diodes

 Detail description of high power led diodes

Product Name

red green yellow white 1w 3w led high power diodes

Chip brand

Epistar,brigelux,Epileds (Available)

Color temperature

2500-25000k are available

High intensity

15-240lm

Power

1W , 3W

Current

350mA/500mA/750mA

Voltage

2.0-4.0V

Available Color

Warm White/ White/Cold white, Red,Green,Blue,Yellow,RGB,UV and so on

Operating Temperature Range

-20°C to  80°C

Emmiting angle



140° degrees

Lifespan

up 50,000h





1W&3W high power led diode



ColorCategoryWavelength or CCTLuminous FluxCRIForward CurrentForward VoltageViewing Angle
Cool White1W LED3700-20000K80-130lm65-85350mA3.0-3.6V140°
Warm White2400-3500K
Cool White3W LED3700-20000K160-240lm750mA3.5-4.0V
Warm White3700-20000K
Yellow1W LED580-595nm35-45lm 350mA2.0-2.6V
3W LED90-120lm 750mA2.5-2.8V
Red1W LED620-640nm30-60lm 350mA2.0-2.6V
3W LED50-80lm 750mA2.5-2.8V
Green1W LED520-530nm60-80lm 350mA3.0-3.6V
3W LED120-150lm 750mA3.6-4.0V
Blue1W LED450-470nm15-30lm 350mA3.0-3.6V
3W LED30-50lm 750mA3.6-4.0V









led diodes Features:



1. Chip Material: AIGalnP
2. Shape: Round LED, oval LED, straw hat LED, helmet LED, square LED, flat top LED, bullet LED, concave LED, rectangle LED
3. Available Size: 2mm, 3mm, 5mm, 8mm, 10mm, 12mm,20mm
4. Lens type: Water clear,colored diffuse ,color transparent
5. Emitted color: Red, White, Yellow, Orange, yellow-green, Green, Blue,Purple, RGB flash
6. Different angle available
7. Low power consumption, high intensity, uniform illumination
8. Solid-state, high shock and vibration resistant
9. Major reduction in power cost
10. No RF interference
11. Maintenance free, easy installation
12. Long life 70,000-100,000hours
13. Superior ESD protection






 Certification:











Packaging of dip led components

Normally, 1000pcs/set.







Payment & Shipping



Our products are all shipped by air normally, time-sensitive,shipped by DHL,FedEx,TNT,UPS and so on.
Samples in stock,we can send them in 2 days,and orders normally is sent out by 5-7days,or according to the  quantity.













Our service

1. 3 years warranty
2. 5 years technical service team
3.professional sales team

4.Free Sample is available

5.Fast delivery
6.Aiming at the consult of "high quality,zero defect",give you the best quality,best service.



About US



Dongguan Pengyuan Opto-electronic Techonology Co.,Ltd was established in 2003,which is located in Shilong,Dongguan.We are a professional manufacturer of light-emitting diode LED, Dip LED, SMD LED, Infrared LED, Strip LED, High Power LED and LED bulbs.

PY has strong technical spectrophotometric machines. The annual output reached 50,000KK.

With an increasing number of orders each year,our business quickly expands to global markets.


Quality and Safety:
We have implemented a strict and complete quality control system, which ensures that each product can meet quality requirements of customers. Besides, all of our products have been strictly inspected before shipment.PY has commissioned SGS product testing and passed CE, RoHS, FCC, CCC, ULR, PHAS, PFOS / A and ISO9000 certifications.

Our aim is to help customers realize their goals. We are making great efforts to achieve this win-win situation and sincerely welcome you to join us.
